BSSTREAT * Precision Pre filter Folding Filter Element
Product Description
The BSSTREAT* series of foldable backwashable filter cartridges are mainly designed for the high requirements of removing iron oxide in industrial condensate water systems. Different filter materials can provide absolute filtration accuracy ranging from 1.0 to 25 microns to meet the requirements of various condensate water systems. Like all condensate filter elements of SOAP Technologies, we offer a variety of filter element connectors to meet the requirements of new systems or filter element replacement projects.
Product performance
• The absolute filtration accuracy ranges from 1 to 25 microns
• The filtration efficiency is 99.9%
• Higher filtration area and higher dirt-holding capacity
• Fix the microporous structure to prevent dirt from leaking when the pressure difference increases
l Product parameters
|
Product parameters： |
Polypropylene |
|
Internal support： |
Polypropylene |
|
End cover： |
Polypropylene |
|
Net cage： |
Polypropylene |
|
Gasket/O-ring： |
Ethylene propylene diene monomer (EPDM) rubber |
|
Filtration accuracyum： |
1.0，2.0，5.0，10，25 |
Product size
|
Standard length： |
50″ ,60″ ,70″ ,80″ |
|
Outer diameter： |
2.5″2.0″ |
|
Outer diameter： |
1″ |
|
Maximum operating temperature： |
85℃ |
|
Maximum operating pressure difference： |
2.5bar at 60℃ |
|
Maximum backwash pressure difference： |
5.5bar at 60℃ |
Filtration accuracy (microns) under different filtration efficiencies
|
Efficiency |
99.9% |
99% |
98% |
|
010 |
1.0 |
0.6 |
0.3 |
|
020 |
2.0 |
1.5 |
1.0 |
|
050 |
5.0 |
4.0 |
3.0 |
|
100 |
10 |
8.0 |
7.0 |
Displaying the filtration accuracy under different filtration efficiencies can better assist engineers in adapting to various water quality requirements and applications. The results shown in the table are the results of multiple tests conducted on 10 "long filter elements under strict laboratory conditions. In the power condensate water system, based on practical experience, it is recommended to use filter elements of 1 micron or 5 microns. To extend the operation and service life of the filter elements, it is suggested that new units adopt start-up filter elements with a precision of 10 microns.
